Comparison between TCP/IP and OSI Model
Comparison between TCP/IP and OSI models is critical because protocols that make up the TCP IP protocol suite can also be described in terms of the OSI reference model. The network access layer and application layer of the TCP IP models are further divided, and the OSI model describes discrete functions that must occur at these layers. Both models are widely used networking models for communication. The critical difference between the two is that OSI is a conceptual model that is not practically used for communication. In contrast, TCP IP establishes a connection and communicates through the network.
The network Access layer of the TCP/IP model does not specify which protocols to use when transmitting over a physical medium. It only describes the handover from the Internet layer to the physical layer. On the other hand, the OSI Layer physical and data link layers discuss the basic process of accessing the media and the physical means of sending data over a network.
Network Layer of OSI and Internet Layer of TCP/IP Model
The network layer maps directly to the TCP/IP Internet layer. This layer explains protocols that address and route messages from end to end an internetwork.
Transport Layer
The transport layer maps directly to the TCP IP Transport layer. This layer explains the general services and functions that ensure the ordered and reliable delivery of data between source and destination hosts.
TCP/IP Application Layer
The application layer of the TCP IP model includes several protocols that give specific functionality to various end-user applications. The OSI Model Layers 5, 6, and 7 used as references for application software developers and vendors to produce products that operate on networks.
Comparison between TCP/IP and OSI Models Protocols
Both the TCP IP and OSI models commonly used when referring to protocols at various layers. OSI is a generic, protocol-independent standard, acting as a communication gateway between the network and end user. TCP/IP model is based on standard protocols around which the Internet has developed. It is a communication protocol, which allows connection of hosts over a network. OSI is a reference model around which the networks built. Generally, it is a guidance tool.TCP IP model is, in a way implementation of the OSI model.
TCP/IP Layers | OSI Layers | Key Responsibility | Common Protocols |
Application Layer | Application Layer | User Application Services | DNS, NFS, BOOTP, DHCP, SNMP, RMON, FTP, TFTP, SMTP, POP3, IMAP, NNTP, HTTP, Telnet |
Presentation Layer | Data Translation, Compression and Encryption | SSL, Shells and Redirectors, MIME | |
Session Layer | Session Establishment, Management and Termination | NetBIOS, Sockets, Named Pipes, RPC |
Transport Layer | Transport Layer | Process-Level Addressing, Multiplexing/ De-Multiplexing, Connections, Segmentation and Reassembly, Acknowledgments and Retransmissions, Flow Control | TCP and UDP, SPX, NetBEUI/NBF |
Internet Layer | Network Layer | Logical Addressing, Routing, Datagram Encapsulation, Fragmentation and Reassembly, Error Handling and Diagnostics | IP, IPv6, IP NAT, IPsec, Mobile IP, ICMP, IPX, DLC, PLP, Routing protocols such as RIP and BGP |
Network Access Layer | Datalink Layer | Logical Link Control, Media Access Control, Data Framing, Addressing, Error Detection and Handling, Defining Requirements of Physical Layer | IEEE 802.2 LLC, Ethernet Family, Token Ring, FDDI and CDDI, IEEE 802.11 (WLAN, Wi-Fi), HomePNA, HomeRF, ATM, SLIP and PPP |
Physical Layer | Encoding and Signaling, Physical Data Transmission, Hardware Specifications, Topology and Design | Physical layers of most of the technologies listed for the data link layer |
OSI has 7 layers and TCP has 4 Layer model. following is the comparison model of both layer.
Key Differences between TCP/IP and OSI Model
Feature | TCP/IP Model | OSI Model |
---|---|---|
Layers | 4 layers | 7 layers |
Design Philosophy | Top-down (practical) | Bottom-up (theoretical) |
Real-World Use | Internet standard | Conceptual framework |
Protocol Dependency | Protocol-specific (IP, TCP) | Protocol-agnostic |
Tangibility | Implemented in practice | Abstract reference tool |
Critical Distinctions
Purpose:
- TCP/IP is a protocol suite used globally for internet communication.
- OSI is a theoretical model for standardizing network functions.
Layer Architecture:
- TCP/IP combines OSI’s Layers 5–7 into a single Application layer.
- OSI explicitly separates services (e.g., Session vs. Presentation layers).
Adoption:
- TCP/IP dominates modern networks due to its simplicity and scalability.
- OSI guides protocol design but is rarely implemented in full.
Approach:
- TCP/IP follows a client-server architecture.
- OSI emphasizes modularity for interoperability.
Practical Implications
- Developers: Use OSI to design cross-compatible software (e.g., VPNs leveraging Layer 3).
- Network Engineers: Rely on TCP/IP for configuring routers, firewalls, and servers.
- Troubleshooting: OSI’s layered structure helps isolate issues (e.g., physical vs. application-layer faults).
Conclusion – Comparison between TCP/IP and OSI Models
While the OSI model provides a comprehensive framework for understanding networks, TCP/IP is the backbone of modern connectivity. Their comparison underscores the importance of balancing theoretical concepts (OSI) with real-world implementation (TCP/IP). For deeper insights, explore:
FAQs
-
The TCP/IP model is a practical, protocol-oriented standard with four layers, developed earlier for internet use. The OSI model is a theoretical framework with seven layers, designed by ISO for standardized network communication. TCP/IP combines some OSI layers, like the application, presentation, and session layers, into one.
