The Internet Control Message Protocol (ICMP) is a critical component of the IP suite, used for error reporting, diagnostics, and network management. While ICMPv4 supports IPv4 networks, ICMPv6 is its enhanced counterpart for IPv6, introducing new features like the Neighbor Discovery Protocol (NDP). For CCNA and CCNP students, understanding ICMP is essential for configuring and troubleshooting Cisco networks.

This article explains the differences between ICMPv4 and ICMPv6, focusing on ICMPv6’s advanced features like Router Solicitation (RS), Router Advertisement (RA), Neighbor Solicitation (NS), and Neighbor Advertisement (NA). We’ll also cover practical Cisco configurations, troubleshooting tips, and how these protocols apply to real-world scenarios. At the end of the article simulator is included for all the related commands in the article.

ICMPv4 vs. ICMPv6: Key Differences

ICMPv4 and ICMPv6 serve similar purposes—error reporting and diagnostics—but ICMPv6 introduces enhanced features for IPv6 networks. ICMPv6 messages are encapsulated in IPv6 packets and include the Neighbor Discovery Protocol (NDP), which replaces ARP and adds new functionalities like Stateless Address Autoconfiguration (SLAAC).

Comparison of ICMPv4 and ICMPv6

ICMPv6’s NDP includes four key protocols: Router Solicitation (RS), Router Advertisement (RA), Neighbor Solicitation (NS), and Neighbor Advertisement (NA). These are explained in detail below.

Router Solicitation (RS) Message

Router Solicitation (RS) messages are sent by IPv6 hosts to prompt routers to send Router Advertisement (RA) messages immediately, rather than waiting for periodic RA broadcasts. This is critical for Stateless Address Autoconfiguration (SLAAC), where hosts dynamically obtain IPv6 addresses.

• Purpose: Requests network configuration details (e.g., prefix, default gateway).
• Destination: Sent to the all-routers multicast address (FF02::2).
• ICMPv6 Type: 133.
• When Sent: At system startup or when a host needs an updated configuration.

Cisco Configuration Example

To enable a Cisco router to respond to RS messages, configure IPv6 on an interface:

Router(config)# interface GigabitEthernet0/0
Router(config-if)# ipv6 address 2001:db8::1/64
Router(config-if)# ipv6 nd ra interval 200
Router(config-if)# no ipv6 nd suppress-ra

This configuration sets the RA interval to 200 seconds and ensures RA messages are sent in response to RS messages.

Router Advertisement (RA) message

Router Advertisement (RA) messages are sent by IPv6 routers to provide hosts with configuration information for SLAAC. RA messages are sent periodically or in response to RS messages.

• Purpose: Provides prefix, prefix length, default gateway, DNS server, MTU, hop limit, and timers for neighbor discovery.
• Destination: Sent to the all-nodes multicast address (FF02::1).
• ICMPv6 Type: 134.
• Key Flags:
  • Managed Address Configuration (M): Indicates DHCPv6 for address assignment.
  • Other Configuration (O): Indicates DHCPv6 for other settings (e.g., DNS).

Cisco Configuration Example

To configure RA messages on a Cisco router:

Router(config)# interface GigabitEthernet0/0
Router(config-if)# ipv6 address 2001:db8::1/64
Router(config-if)# ipv6 nd prefix 2001:db8::/64
Router(config-if)# ipv6(nd ra dns server 2001:db8::53

Troubleshooting Tip

Use the command show ipv6 routers on a Cisco device to verify received RA messages.

Neighbor Solicitation (NS) and Neighbor Advertisement (NA) Messages

ICMPv6 Neighbor Solicitation (NS) and Neighbor Advertisement (NA) messages are part of the Neighbor Discovery Protocol (NDP), replacing ARP in IPv4. They serve two main purposes: address resolution and Duplicate Address Detection (DAD).

Address Resolution

When the device knows the destination IPv6 unicast address on the same link but does not know the destination device’s MAC address, the Address Resolution is used to know its MAC address, similarly to an ARP Request for IPv4. To resolve the destination’s MAC address, the device will send an NS message to the solicited-node address. The message will contain the destination IPv6 unicast address. The destination device will respond with an NA message containing its Ethernet MAC address. The NS message includes:

• ICMPv6 Type: 135.
• Target Address: The IPv6 address to resolve.
  The destination device responds with an NA message (ICMPv6 Type 136) containing its MAC address.

Duplicate Address Detection (DAD)

IPv4 nodes use gratuitous ARP to detect a duplicate unicast IPv4 address on the local link. Similarly, IPv6 nodes use Neighbor Solicitation messages (NS message) to identify the uniqueness of an address on the local link in a process known as Duplicate Address Detection (DAD). The device will send an NS message with its IPv6 address as the targeted IPv6 address. If another device on the network has this address, it will respond with an NA message. This NA message will notify the sending device that the address is in use. If a corresponding NA message is not returned within a certain period, the unicast address is unique and acceptable.

DAD ensures an IPv6 address is unique on the local link. The process:

1. A device sends an NS message with its tentative IPv6 address as the target.
2. If another device uses the address, it responds with an NA message.
3. If no NA is received within a timeout period, the address is unique.

Cisco Verification

To check neighbor entries on a Cisco device:

Router# show ipv6 neighbors

This displays the IPv6 address, MAC address, and interface of discovered neighbors.

Troubleshooting and Security Considerations

Troubleshooting ICMPv6

Use these Cisco commands to troubleshoot ICMPv6 issues:

• Verify RA messages: show ipv6 routers
• Check neighbor cache: show ipv6 neighbors
• Debug NDP: debug ipv6 nd

Example:

Router# debug ipv6 nd
ICMPv6-ND: Received RA from 2001:db8::1 on GigabitEthernet0/0

Security Considerations

RA Spoofing: Malicious devices can send fake RA messages to disrupt SLAAC. Use RA Guard on Cisco switches:

Switch(config)# ipv6 nd raguard policy RAGUARD
Switch(config-nd-raguard)# device-role router
Switch(config)# interface GigabitEthernet0/1
Switch(config-if)# ipv6 nd raguard

DAD Attacks: Attackers can claim addresses during DAD. Enable Secure Neighbor Discovery (SEND) where supported.

ICMPv4/ICMPv6 Network Simulator

Do not use the short form of the command; use the full form, because the short form of the command is not added to the simulator. The simulator will only work for commands in this article or some basic commands.

Router> enable
Router# configure terminal
Router(config)# interface GigabitEthernet0/0
Router(config-if)# ipv6 enable
Router(config-if)# ipv6 address 2001:db8::1/64

Router(config-if)# ipv6 nd ra interval 200
Router(config-if)# no ipv6 nd suppress-ra
Router(config-if)# ipv6 nd prefix 2001:db8::/64

Switch(config)# ipv6 nd raguard policy RAGUARD
Switch(config-nd-raguard)# device-role router
Switch(config)# interface GigabitEthernet0/1
Switch(config-if)# ipv6 nd raguard attach-policy RAGUARD

Router# show ipv6 neighbors

Router# show ipv6 routers

Router# debug ipv6 nd

Router# ping ipv6 2001:db8::1
